TACT Logo EpicEdge

Your Old Printer Technology
Just Got Edged Out

Featuring an unmatched 300 DPI print quality, a high-speed firmware uploading solution and a single interface board for all games, there is no question about it. Have an “Edge” over the rest with the most innovated printer on the market.

GC Img EpicEdge

Features

GC Img EpicEdge

300 DPI

Featuring an unmatched 300 DPI print resolution, the Epic Edge improves ticket readability and acceptance by bill validators, all while enabling casino operators to print eye-catching promotional coupons and bonus tickets with Epicentral.

GC Img EpicEdge

Speedy Firmware Uploading

Faster than ever, the printer has two additional high-speed interfaces to simplify firmware updates and graphic downloads. A micro SD card updates the printer with no need to carry a laptop or turn off the slot machine.

GC Img EpicEdge

One Printer For All Games

The Epic Edge is fully equipped with serial and USB interfaces that are all conveniently built into a single board. This means you only need to inventory a single printer, for any game.

GC Img EpicEdge

Eco-Friendly Tickets

The “Edge” contains an adjustable ticket bucket that allows operators to use smaller, paper-saving tickets to work with ecological programs being implemented in casinos.

Additional Features

GC Img EpicEdge

Patented Jam-Free Bezel

Our TicketBurst™ technology prints and bursts each ticket before presenting the ticket to the player. This eliminates player interference, ensuring a jam free transaction and maximum up time.

High Connection Speed

Our ServerPort™ enables value added apps, such as our Epicentral coupon bonusing system. Casino management systems that integrate Epicentral also connect to Epic Edge via the ServerPort, as will eTITO systems.

GC Img EpicEdge
GC Img EpicEdge

Color-Coded Chassis Rails

While the Epic Edge and Epic 950 coexist on the slot floor, different color rails in the outer chassis and other design differences ensure the Epic Edge printers install correctly.

Hot Swappable

Nobody wants to power down a game in order to swap out a printer. With the Epic Edge, the outer chassis with its game connection stays in the game, so there is no need to power down just to swap out a printer. Easy peasy.

GC Img EpicEdge

Ultra-Reliable

The Epic Edge is built on the reliability of the Epic 950, which is so dependable that less than .03 percent of casinos have reported any sort of failure with the printer during the initial warranty period. We expect that number to decrease even more with the “Edge.”

Built With Purpose

The “Edge” is intricately designed with essential features from the Epic 950, the industry-award winning TITO printer.

Free Firmware Updates

We believe in cost efficiency as much as stellar customer service. As such, we offer free firmware upgrades.

Amazing Support

TransAct offers complimentary tech support both online and on-site from experienced specialists you can trust

Customer Oriented

We value our customers and always welcome feedback! Feel free to contact us if you ever have a question or suggestion.

Technical Specifications

Resolution 300DPI
Print Width 2.44 in / 62 mm
Print Speed 5 inches per second
125 mm per second
Dimensions 4.46W x 11.25D x 2.66H (inches)
113.3W x 285.75D x 67.6H (mm)
Weight 3.8 lbs / 1.7 kg
Interfaces Single Board: USB, Serial, Netplex™
Power Supply 24 VDC: 2.2 Amps Maximum
Operating Temperature 41 to 140 F at 10 to 90% RH
5 to 60 C at 10 to 90% RH
Storage & Shipping Temperature 14 to 122 F at 5 to 90% RH
-10 to 50 C at 5 to 90% RH
Print Head Life 43.45 miles / 70km
Reliability Less than .03% failures
(3 per 10,000)
Memory Capacity 8MB RAM and 4MB Flash for
printer operations
Resolution 300DPI
Print Width 2.44 in / 62 mm
Print Speed 5 inches per second
125 mm per second
Dimensions 4.46W x 11.25D x 2.66H (inches)
113.3W x 285.75D x 67.6H (mm)
Weight 3.8 lbs / 1.7 kg
Interfaces Single Board: USB, Serial, Netplex™
Power Supply 24 VDC: 2.2 Amps Maximum
Operating Temperature 41 to 140 F at 10 to 90% RH
5 to 60 C at 10 to 90% RH
Storage & Shipping Temperature 14 to 122 F at 5 to 90% RH
-10 to 50 C at 5 to 90% RH
Print Head Life 43.45 miles / 70km
Reliability Less than .03% failures
(3 per 10,000)
Memory Capacity 8MB RAM and 4MB Flash for
printer operations
