TACT Logo EpicTR80

The New Gaming Printer
with Unmatched Functionality

The Epic™ TR80 thermal roll printer is packed with features and functionality that defy its small footprint. This printer is the ideal choice when game or kiosk cabinet space is limited for applications, such as Amusement with Prizes (AWP), Skill with Prizes (SWP), Sports Betting and Video Lottery Terminals (VLT).

Features

GC Img Epic888

Accommodating Straight Paper Path

Holds 4” and 6” (101mm or 152mm) diameter rolls. Door swings up for automatic paper loading and simple feeding.

TACT Img EpicTR80

Patented Jam-Free Bezel

Ticket Burst™ technology prints and cuts receipts before presenting. Eliminates jams caused by player interference.

GC Img Epic888

Dual Interfaces

USB and Serial for easy integration.

Configuration Options

TACT Img EpicTR80

Unique Paper Handling

The variable-position spindle allows paper rolls to be mounted behind or below the printer mechanism.

TACT Img EpicTR80

Flexible Dual-Sided Paper Mounting Arm

Position mounting on left or right side of the printer for easy cabinet integration

Looking for support?

Find product support including documents, drivers, and utilities.

Find It Here

Technical Specifications

Resolution 203 DPI
Print Width 3.15 inches (80 mm)
Print Speed 6 inches (152 mm) per second
Dimensions 5.5 W x 6.0 D x 4.0 H (inches)
139.7 W x 152.4 D x 101.6 H (mm)
Weight 4.0 lbs (1.8 Kg)
Interfaces USB & Serial (14-pin)
Media – Thermal Monochrome
– 80 mm or 82.5 mm width
– 4 inch (101 mm) or 6 inch (152.4 mm) diameter roll
– Paper caliper 2.1 to 3.5 Mil
– Fixed (black dot) or variable length tickets
Power Supply 24VDC: 3 Amps Max



Operating Temperature 41 to 122 F at 10 to 90% RH
5 to 50 C at 10 to 90% RH
Storage & Shipping Temperature 14 to 122 F at 10 to 90% RH
-10 to 50 C at 10 to 90% RH
Print Head Life 62 miles (100 Km) POS Paper
45.9 miles (74 Km) Lottery Paper
Cutter Life 1M Cuts (Lottery grade paper)
Compliance IEC 62368-1, CE Mark, RohS, TUV NRTL MARK
Printer Drivers USB
Barcode Code 31, 93, 128, UPC-A, UPC-E, EAN-8, EAN-13, Codabar, ITF, PDF417,  and Interleaved 2 of 5
Resolution 203 DPI
Operating Temperature 41 to 122 F at 10 to 90% RH
5 to 50 C at 10 to 90% RH
Storage & Shipping Temperature 14 to 122 F at 10 to 90% RH
-10 to 50 C at 10 to 90% RH
Print Head Life 62 miles (100 Km) POS Paper
45.9 miles (74 Km) Lottery Paper
Cutter Life 1M Cuts (Lottery grade paper)
Compliance IEC 62368-1, CE Mark, RohS, TUV NRTL MARK
Printer Drivers USB
Barcode Code 31, 93, 128, UPC-A, UPC-E, EAN-8, EAN-13, Codabar, ITF, PDF417,  and Interleaved 2 of 5
Print Width 3.15 inches (80 mm)
Print Speed 6 inches (152 mm) per second
Dimensions 5.5 W x 6.0 D x 4.0 H (inches)
139.7 W x 152.4 D x 101.6 H (mm)
Weight 4.0 lbs (1.8 Kg)
Interfaces USB & Serial (14-pin)
Media – Thermal Monochrome
– 80 mm or 82.5 mm width
– 4 inch (101 mm) or 6 inch (152.4 mm) diameter roll
– Paper caliper 2.1 to 3.5 Mil
– Fixed (black dot) or variable length tickets
Power Supply 24VDC: 3 Amps Max
Download the Spec Sheet
