TACT Logo EpicEdgeTT

For Table Games, Players’ Clubs or Cash Desks

Addressing a growing need in the marketplace for table top printing, TransAct’s new Epic EdgeTT version packages the Epic Edge printer, power supply and ServerPort in a tidy, compact design for use on table games, players’ club desks and cash desks.

GC Img EpicEdgeTT

Features

GC Img EpicEdgeTT

Powered by Epic Edge®
TITO Printer

The industry’s newest and most advanced TITO printer with 300 DPI and fastest firmware uploading

GC Img EpicEdgeTT

ServerPort™ Optional

Mounts internally for easy upgrade path to Epicentral- the only enterprise promotional couponing software

Additional Features

GC Img EpicEdgeTT

Patented Jam-Free Bezel

TicketBurst™ technology eliminates jams and player interference

GC Img Epic950

Interfaces

Serial or USB

GC Img EpicEdgeTT

Versatile Ticket Capacity

200 or 400 Standard (156mm) or Short (120mm) Tickets

GC Img EpicEdgeTT

Internal Power Supply

Makes a neat, compact package mounted inside for no visible external power brick

Applications

Epicentral®

Ensures only approved apps and functions are installed and run on your terminals

Table Games

Real-time delivery of OS, app and security updates via OTA

Cash Desks

Easy access to settings and preferences with a quick swipe

Players’ Club

Access technical support via phone, email or live chat, and work with highly trained experts to resolve terminal issues

Looking for support?

Find product support including documents, drivers, and utilities.

Technical Specifications

Resolution 300 DPI
Print Width 2.44 inches (62 mm)
Print Speed 5 inches (125 mm) per second
Dimensions 5 W x 14.5 D x 5.5 H (inches)
127 W x 368 D x 140 H (mm)
Weight 4.5 lbs (2.0 Kg)
Interfaces USB or RS-232 Serial
Power Supply 100-240 VAC, 50-60Hz, 1.5A
Operating Temperature 41 to 140 F at 10 to 90% RH
5 to 60 C at 10 to 90% RH
Storage & Shipping Temperature  14 to 122 F at 5 to 90% RH
-10 to 50 C at 5 to 90% RH
Print Head Life 43.45 miles (70 Km)
Memory Capacity 8MB RAM and 4MB Flash for
printer operations
Resolution 300 DPI
Print Width 2.44 inches (62 mm)
Print Speed 5 inches (125 mm) per second
Dimensions 5 W x 14.5 D x 5.5 H (inches)
127 W x 368 D x 140 H (mm)
Weight 4.5 lbs (2.0 Kg)
Interfaces USB or RS-232 Serial
Power Supply 100-240 VAC, 50-60Hz, 1.5A
Operating Temperature 41 to 140 F at 10 to 90% RH
5 to 60 C at 10 to 90% RH
Storage & Shipping Temperature  14 to 122 F at 5 to 90% RH
-10 to 50 C at 5 to 90% RH
Print Head Life 43.45 miles (70 Km)
Memory Capacity 8MB RAM and 4MB Flash for
printer operations
